2.0V Fiber Optic HDMI cable is suitable for the home theaters ,Commercial theaters,Medical equipments, sports venues , factory automation,and large viewing hall and international conference centre, exhibition hall ,and so on others required high-definition equipment .
Features:
√ Maximum support 4k@60Hz,Ethernet ,Full color sampling4:4:4,Audio return channel
√Maximum bandwidth up to 18Gbps(single channel 6 Gbps,3 Channels)
√Low power consumption(≤250mw).Max.working current is 48ma.
√Ensure distortionless definition to transmit image signal without compression
√support HDCP 2.2/CEC/EDID
√Plug and play ,its easy to use it without adding external power and signal amplifier
√Maximum transmission length up to 100 meters
√Transmits high frequency signal and makes zero electromagnetic interference
Specification:
| Item: | Specification: |
| Connector type | HDMI type A to HDMI type A |
| Conductor | TC (Fiber X4C)*1+(30#*1P+D+AL)+30#*4C+26#*1C+F+AL |
| Jacket | TPE |
| Jacket Dia | 4.7mm |
| Transmission Bandwidth | 18G |
| Photoelectric Converter | 4CH 850nmVCSEL/PIN |
| Power consumption | ≤250mW |
| Power | 5V |
| Ultimate Bending radius | D15mm. |
| Continuous Tension | 100N(15min) |
